w213 rattle/noise fixes

Page may contain affiliate links. Please see terms for details.

grumpytosser

Active Member
Joined
Jul 3, 2016
Messages
225
Car
2017 s213 AMG Line Premium Plus +++
Hi i seem to be making good progress in getting rid of the rattles in the w/s213

so thought id try to list them all here

first step in all of these is disconnect the battery as you will be disconnecting devices and switches so better to be safe

main tools you will need for these
10mm socket, T20 and t25 driver/bit

optional pics and prody things to aid disconnecting cables
trim tools

then the materials
pretty much everything can be done with
fabric loom tape TESA TAPE 51608 ADHESIVE CLOTH FABRIC WIRING LOOM HARNESS 25mm 19mm 9mm | eBay
felt pads that you use for furniture on hard floors Floor Protector Self-Adhesive Felt Sticky Pad Home Furniture Anti-Scratch Tape | eBay

but this stuff is great its a plasic lubricant that is designed for interior noises this one sticks to plastic but will stop noises against metal and leather as long as one side is plastic. its not like a grease it doesnt migrate you rub it on and let it dry and there you go

AC-F27 AC F27 – Newgate Simms


Open bonnet
remove this cover by turning the 2 plastic catched 90 degrees

Remove the dust filter tab on each side press in and pull

disconnect the negative terminal with 10mm socket then make sure it cant contact the negative terminal again


Center console creaking

open armrest

remove these 2 rubber bumpers they just pull out

remove these 2 T20 screws

Pry out the armrest release button

remove these 2 T20 screws

pull up un the center console

its only held in by a few clips then slide it out from the dash untill you can start disconnecting the wires from the console

disconnect the wite cable and the black one

remove the green one from the front keyless entry receiver

disconnect the 12v/cigarette lighter

to completly remove it you also need to disconnect the connector for the hvac controls, the clock, the media controls and the abient lighting led's but to do this it isnt 100% needed

remove the 2 T20 screws holing on the cupholder/ashtray cubby

this then comes away from the trim panel

remove the silver trim by lifing these tabs


next you need to remove the lid covering the hidden part of the cubby i found it easier prying it up from the back

sorry no photo :(

then you need to either use fabric tape to cover the edges of the cubby box or some AC-F27 antifriction coating for plastic



Attachments

  • IMG_20210720_172328.jpg
    1 MB · Views: 4
Last edited:
Part 2

just stick it anywhere 2 surfaces can touch and rub

maybe not 100% needed i then stuck tape everywhere anything may possibly rub



you can also take the HVAC and media controls aprt and try and treat them but thats more hassle than is maybe needed this should get rid of the creaking when you rest you leg on the console anyway

door cards creaking on the door pull

you most likely have the door pull on the door card that creaks when you grip it this is annoying as it really does make it feel more like a fiat panda than a £40K+ car
this one is actually somewhat destructive so you will need some screws from mercedes

I have found these ones work A0009907006 55p each ive only done the rear doors so far but it seems you need 3 per door

this is work in progress at the moment

remove the door card held on with 2xT25 screws

pop the door card off using fingers or trim tools unhook the door lock popup thingy
disconnect the interior door opener pull green sheath back then disconnect the hook
disconnect the speakers and disconnect the 2 or 3 blue plugs from the door module

take it somewhere to work on

remove the noise reduction felt from the door card

remove the window switch by putting a tril tool in the gap at the front pulling for ward slightly then it just pulls up from the top

remove the 5 screws from the door card that secure the armrest to the door

cut off the 3 plastic welds holding the door rest of the door pull/armrest to the door

then the leather cover will come off

coat all the plastic edges with AC-F27 or tape let it dry if using AC-F27


pop the cover back on

and use the aditional purchased screws to secure where the plastic welds were this is how its supposed to be fixed



i will update the picturs in more detail when i do the other doors

also creaking when you put your arm on top of door card, rattle in doors, rattle under rear seat, b pillar buzzing, hvac control unit in dash etc etc

if you have any others let me know and i will see what i can do

Front Door

thought i could edit my previous post but no

video of door after
Mercedes W213 door after treating with AC-F27

You most likely have the door pull on the door card that creaks when you grip it this is annoying as it really does make it feel more like a fiat panda than a £40K+ car
this one is actually somewhat destructive so you will need some screws from mercedes

I have found these ones work A0009907006 55p each ive only done the rear doors so far but it seems you need 5 per door

remove the door card held on with 2xT30 screws

pop the door card off using fingers or trim tools unhook the door lock popup thingy
disconnect the interior door opener pull green sheath back then disconnect the hook
disconnect the speakers and disconnect the 2 or 3 blue plugs from the door module

take it somewhere to work on

remove the noise reduction felt from the door card


remove the window switch by putting a trim tool in the gap at the front pulling for ward slightly then it just pulls up from the top


remove the 6 screws from the door card that secure the armrest to the door and cut off the 5 plastic welds holding the door rest of the door pull/armrest to the door

InkedIMG_20210813_174908_LI markup.jpg

then the leather cover will come offjust start prying it away the from the door handle frame


coat all the plastic edges with AC-F27 or tape let it dry if using AC-F27


Last edited:
Door Trim noises

remove the door card held on with 2xT30 screws

pop the door card off using fingers or trim tools unhook the door lock popup thingy
disconnect the interior door opener pull green sheath back then disconnect the hook
disconnect the speakers and disconnect the 2 or 3 blue plugs from the door module


remove the felt insulation

The trim piece is help on by 11 clips these are tricky to remove or atleast they were for me :(
best way i found is to wedge a flat blade screw driver between the 2 metal catches and then push down on the plastic retaining pin. they get easier once you get 1 or 2 and if you can wedge a trm tool in a gap to apply a little force it may help

once remove coat all the palstic that comes into contact with anyting with ac-f27 on the ddor card and on the trip piece you have removed i even removed the seat controls and took the trim pieces off those and treated them

overhead panel sunglasses holder

this doesnt ratttle but sounds cheap as hell when you toch it and it gracunces and creaks

Overheap panel video before treatment

Overhead panel video after treatment



Again disconnect battery

stick trim tool in the front middle of the panel there is a bar up there you need to push that releases 2 tabs it will then drop down

disconnect the cables


Take it somewhere to work on it (it may take a while depending on how much you want to take it apart :) )


Release these clipa on both sides and the front this releases the trip ring. Coat all the edges with AC-F27

Flip it over and remove all the screws

split it apartand coat everything with AC-F27 where it contacts anything



pop off the covers they just pull off again coat all the edges


Remove the sunroof switch if you have one and coat that


basically just coat everything that may tough something :)

Awesome work. Well done. 👏👏👏👏
thank you it means alot!

i keep realising i am not taking enough photos but im just focusing on getting them done. i hope it helps some people as onceit stops rattling its so much nicer !

i still cant find my most annoying rattle though :(

Center armrest and rear vents

I found my armrest creaked when i used it and also the rear vents creaked if you pressed on the housing at the rear of the center console

required same as above t20 driver and AC-F27

Remove the 2 rubber caps

remove the 2xt20

lift up the trim


remove these 2x t20

lift up te center console a bit

disconnect the ambient lighting for the center armrest cubby the white plug just gentally pull the black led end off the light tube

remove the carpet for the cubby

remove the t20 screw at the back

pull at the top of the rear cover to remove the airvents


and these 2 t20

then pusin these 2 tabs and lift up the top of the frame then start to pull toward the back of the car it will then come off


apply AC-F27 again on all surfaces that will touch any plasick so masically slather it on anywhere that isnt visible :) the little cubby at the front of the arm rest just pushes off then you can do the edges on that aswell
